Description :

Technical Specifications

Essentials



Vertical Segment                        Desktop

Product Collection                      Intel® Pentium® Gold Processor Series

Processor Number                      G5420

Status                                       Launched

Launch Date                              Q2'19

Lithography                               14 nm

Use Conditions                           PC/Client/Tablet



Performance

# of Cores                                 2

# of Threads                              4

Processor Base Frequency           3.80 GHz

Cache                                       4 MB Intel® Smart Cache

Bus Speed                                 8 GT/s

TDP                                          54 W



Supplemental Information

Embedded Options Available        No





Memory Specifications

Max Memory Size (dependent on memory type)                   64 GB

Memory Types                                                                  DDR4-2400

Max # of Memory Channels                                               2

Max Memory Bandwidth                                                    37.5 GB/s

Processor Graphics ^‡                                                          Intel® UHD Graphics 610

Graphics Base Frequency                                                   350 MHz

Graphics Max Dynamic Frequency                                       1.05 GHz

Graphics Video Max Memory                                              64 GB

4K Support                                                                       Yes, at 60Hz

Max Resolution (HDMI 1.4)‡                                              4096x2304@24Hz

Max Resolution (DP)‡                                                        4096x2304@60Hz

Max Resolution (eDP - Integrated Flat Panel)‡                     4096x2304@60Hz

DirectX* Support                                                              12

OpenGL* Support                                                             4.5

Intel® Quick Sync Video                                                    Yes

Intel® InTru™ 3D Technology                                           Yes

Intel® Clear Video HD Technology                                     Yes

Intel® Clear Video Technology                                           Yes

# of Displays Supported ^‡                                                   3

Device ID                                                                         0x3E90/x93



Expansion Options

Scalability                                                               1S Only

PCI Express Revision                                               3.0

PCI Express Configurations ^‡                                     Up to 1x16, 2x8, 1x8+2x4

Max # of PCI Express Lanes                                     16



Package Specifications

Sockets Supported                                                  FCLGA1151

Max CPU Configuration                                            1

Thermal Solution Specification                                  PCG 2015C (65W)

T_JUNCTION                                                                   100°C

Package Size                                                           37.5mm x 37.5mm











Advanced Technologies

Intel® Optane™ Memory Supported ^‡                                  Yes

Intel® Turbo Boost Technology ^‡                                        No

Intel® vPro™ Platform Eligibility ^‡                                       No

Intel® Hyper-Threading Technology ^‡                                  Yes

Intel® Virtualization Technology (VT-x) ^‡                             Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ^‡      Yes

Intel® VT-x with Extended Page Tables (EPT) ^‡                    Yes

Intel® Transactional Synchronization Extensions                  No

Intel® 64 ^‡                                                                       Yes

Instruction Set                                                                  64-bit

Instruction Set Extensions                                        Intel® SSE4.1, Intel® SSE4.2

Idle States                                                                       Yes

Enhanced Intel SpeedStep® Technology                             Yes

Thermal Monitoring Technologies                                       Yes

Intel® Identity Protection Technology ^‡                               Yes

Intel® Stable Image Platform Program (SIPP)                     No





Security & Reliability

Intel® AES New Instructions                                              Yes

Secure Key                                                                       Yes

Intel® Software Guard Extensions (Intel® SGX)                  Yes with Intel® ME

Intel® Memory Protection Extensions (Intel® MPX)             Yes

Intel® OS Guard                                                               Yes

Intel® Trusted Execution Technology ^‡                                No

Execute Disable Bit ^‡                                                          Yes

Intel® Boot Guard
